Fitment For: Horizontal or vertical intakes on a range of V or flat configuration engines. Can be trimmed to tailor the depth to your application.
Dimensions (in mm):
A: Max External Length = 405
B: Max External Height = 305
C: Max External Depth = 200
D: Depth of Base = 20 (with Base Box)
Air Box Volume (Litres): 32.58
Plus Top Cowl Dimensions with 100mm entries which sit atop of filters.
R01SE0458 K&N Filter Tray for internal if height allows, R01SE6178 ITG Foam 105mm deep dome internal filter, R01SE6183 ITG Dual foam air filter. ITG Dual foam air filter.
